Signal cables according to SIEMENS

Properties of the cables

UV-resistant
CFC-free
Minimum bend radius 7.5 x Ø to 10 x Ø

Halogen-free
Flame-retardant

Approvals:
cURus,
based on VDE,
REACH/RoHS II

Power basic cables assembled to SIEMENS® 6FX8002

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2CB31	(12 x 0.22²)	7.1	1 ÜWM	D-SUB	0.076	0.065
6FX8002-2CA11	(4 x 2 x 0.34² + 4 x 0.5²)	9.1	1 ÜWM	D-SUB	0.116	0.083
6FX8002-2CB51	(4 x 2 x 0.34² + 4 x 0.5²)	9.1	1 ÜWM	D-SUB	0.116	0.083
6FX8002-2CC11	(4 x 2 x 0.34² + 4 x 0.5²)	9.1	1 ÜWM	D-SUB	0.116	0.083
6FX8002-2CD01	(4 x 2 x 0.34² + 4 x 0.5²)	9.1	1 ÜWM	D-SUB	0.116	0.083
6FX8002-2CE07	(4 x 2 x 0.34² + 4 x 0.5²)	9.1	1 ÜWM	D-SUB	0.116	0.083
6FX8002-2CG00	(4 x 2 x 0.34² + 4 x 0.5²)	9.1	1 ÜWM	D-SUB	0.116	0.083
6FX8002-2CA21	(3 x (2 x 0.14²) + 2 x (0.5²))	9.2	1 ÜWM	D-SUB	0.125	0.074
6FX8002-2AD00	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	D-SUB	0.11	0.066
6FX8002-2CA15	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	D-SUB	0.11	0.066
6FX8002-2CA51	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	D-SUB	0.11	0.066
6FX8002-2CA61	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	D-SUB	0.11	0.066
6FX8002-2CF02	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	D-SUB	0.11	0.066
6FX8002-2CH00	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	D-SUB	0.11	0.066
6FX8002-2CM00	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	D-SUB	0.11	0.066
6FX8002-2CA31	(3 x (2 x 0.14²) + 4 x 0.14² + 4 x 0.23² + 2 x 0.5²)	9.6	1 ÜWM	D-SUB	0.129	0.075
6FX8002-2EQ00	(3 x (2 x 0.14²) + 4 x 0.14² + 4 x 0.23² + 2 x 0.5²)	9.6	1 ÜWM	D-SUB	0.129	0.075
6FX8002-2EQ10	(3 x (2 x 0.14²) + 4 x 0.14² + 4 x 0.23² + 2 x 0.5²)	9.6	1 ÜWM	D-SUB	0.129	0.075
6FX8002-2EQ20	(3 x (2 x 0.14²) + 4 x 0.14² + 4 x 0.23² + 2 x 0.5²)	9.6	0.5 ÜWM	D-SUB	0.129	0.075
6FX8002-2CQ31	(3 x (2 x 0.14²) + 4 x 0.14² + 4 x 0.23² + 2 x 0.5²)	9.6	1 Speedtec	D-SUB	0.129	0.075
6FX8002-2EQ31	(3 x (2 x 0.14²) + 4 x 0.14² + 4 x 0.23² + 2 x 0.5²)	9.6	1 Speedtec	D-SUB	0.129	0.075

Additional types upon request.

Varying parameters possible.
ÜWM = coupling nut with full thread

Power basic cables assembled to SIEMENS® 6FX8002

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2CB54	(4 x 2 x 0.34² + 4 x 0.5²)	9.1	1 ÜWM	1 ÜWM	0.116	0.083
6FX8002-2AD04	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	1 ÜWM	0.11	0.066
6FX8002-2CA88	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	1 ÜWM	0.11	0.066
6FX8002-2CF04	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	1 ÜWM	0.11	0.066
6FX8002-2CM04	(3 x (2 x 0.14²) + 4 x 0.14² + 2 x 0.5²)	9.0	1 ÜWM	1 ÜWM	0.11	0.066
6FX8002-2CA34	(3 x (2 x 0.14²) + 4 x 0.14² + 4 x 0.23² + 2 x 0.5²)	9.6	1 ÜWM	1 ÜWM	0.129	0.075
6FX8002-2EQ14	(3 x (2 x 0.14²) + 4 x 0.14² + 4 x 0.23² + 2 x 0.5²)	9.6	1 ÜWM	1 ÜWM	0.129	0.075
6FX8002-2CQ34	(3 x (2 x 0.14²) + 4 x 0.14² + 4 x 0.23² + 2 x 0.5²)	9.6	1 Speedtec	1 Speedtec	0.129	0.075

Additional types upon request.

Varying parameters possible.
ÜWM = coupling nut with full thread

Signal-Drive-CliQ-cables assembled to SIEMENS® 6FX8002

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DC00	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	RJ45 IP20	RJ45 IP20	0.072	0.041

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DC10	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	RJ45 IP20	RJ45 IP67 Plastic	0.072	0.041

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DC10	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	RJ45 IP20	RJ45 IP67	0.072	0.041

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DC20	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	RJ45 IP67	RJ45 IP67	0.072	0.041

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DC30	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	RJ45 IP20	M12 straight	0.072	0.041

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DC34	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	M12 gerade	M12 straight	0.072	0.041

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DC36	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	RJ45 IP67	M12 straight	0.072	0.041

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DC40	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	0.5 Speedtec	RJ45 IP20	0.072	0.041

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DC42	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	0.5 ÜWM	RJ45 IP67	0.072	0.041

Siemens® Assembling	Core number x Cross-section [mm²]	max. ∅ [mm]	Connection Motor	Connection Controler	Cable weight [kg/m]	Copper weight [kg/m]
6FX8002-2DD40	(2 x 2 x 0.20² + 1 x 2 x 0.38²)	7.1	0.5 ÜWM	RJ45 IP20	0.072	0.041

Additional types upon request.
Varying parameters possible.
ÜWM = coupling nut with full thread
